20 kVA 3 Phase Power Conditioner with Voltage Regulator & Battery Backup UPS - Reliable Power Protection for Industrial Equipment, Data Centers, and Critical Infrastructure
$11137.49 $20249.99
-45%
Delivery & Return:Free shipping on all orders over $50
Estimated Delivery:7-15 days international
People:15 people viewing this product right now!
Easy Returns:Enjoy hassle-free returns within 30 days!
Payment:Secure checkout
SKU:42700506
Guranteed safe checkout
Product Description
UPS User Guide:
Integrated Network Card User Guide:
Optional External Battery Cabinet User/Installation Guide:
Spec Sheet/Cut Sheet:
Do you need a PDF quote or a custom emergency backup solution? Email us at .
Multiple Backup Time Options:
| Model Number: | Description (Under Battery Options Drop Down): | Approximate Backup Time At Full Load: |
| BBP-AR-33-20K | UPS With Internal Batteries Only (60 Batteries, 12 Volts, 9 Amp Hours Each) 6.48 KWH | 9 Minutes |
| BBP-AR-33-20K-WEBP | UPS Plus 1 Extra External Battery Pack (140 Batteries, 12 Volts, 9 Amp Hours Each) 15.12 KWH | 22 Minutes |
| BBP-AR-33-20K-W2EBP | UPS Plus 2 Extra External Battery Packs (220 Batteries, 12 Volts, 9 Amp Hours Each) 23.76 KWH | 34 Minutes |
| BBP-AR-33-20K-W3EBP | UPS Plus 3 Extra External Battery Packs (300 Batteries, 12 Volts, 9 Amp Hours Each) 32.40 KWH | 47 Minutes |
| BBP-AR-33-20K-W4EBP | UPS Plus 4 Extra External Battery Packs (380 Batteries, 12 Volts, 9 Amp Hours Each) 41.04 KWH | 1 Hour 0 Minutes |
| BBP-AR-33-20K-W5EBP | UPS Plus 5 Extra External Battery Packs (460 Batteries, 12 Volts, 9 Amp Hours Each) 49.68 KWH | 1 Hour 13 Minutes |
- Model: BBP-AR-33-20K
- 20000 VA (20 kVA) / 20000 Watt (20 kW)
- 3 Phase
- Tower
- Pure Sine Wave Clean Output To Operate And Maximize The Life Of Even The Most Sensitive Electronics
- Online (Double Conversion) - Highest Level Of Protection Available - Battery Power Always Engaged, No Switching Delay
- Accepts Generator Power (Direct or On Automatic Transfer Switch)
- Constant Voltage Regulation
- Constant Frequency Regulation
- Factory Warranty: 3 Years On Electronics And 1 Year Warranty On Batteries
- Optional Extended Warranty: 6 Years On Electronics And 3 Year Warranty On Batteries
- Heavy Duty Industrial Grade For Constant Use
- For Use With Laboratory Instruments
- For Use With Medical Devices
- For Use With Hospital Equipment
- For Use With Sensitive IT Equipment
- 1.0 Power Factor (Unity Power Factor)
- UL Listed
- Management And Monitoring Software Included
- Battery Configuration:
- Built In 60x 12 Volt 9 Amp Hour Batteries
- 9 Minutes (Full Load)
- 18 Minutes (Half Load)
- Add 1 Or More External Battery Cabinets To Extend Backup Time
- For More Information
- Input:
- 138~270 VAC 3 Phase @ 50% Load
- 173~253 VAC 3 Phase @ 100% Load
- Output:
- 208/220 VAC 3 Phase
- Full Load Estimated Run Time On Battery Power:
- 9 Minutes With Internal Batteries
- For Additional Battery Cabinet Configurations
- Operating Temperature Rating: 0C ~ +40C
- Humidity: <95% And Non-Condensing
- Dimensions D X W X H: 815mm X 300mm X 1000mm (32 inches X 12 inches X 40 inches)
- Net Weight: 231 Kgs. (509 lbs.)
