Agilent 1100 Series UPS Battery Backup & Power Conditioner for HPLC - Reliable Power Protection for Laboratory Chromatography Systems

Product Description

• 6,000 VA (6 kVA) / 4,200 Watt (4.2 kW) Maximum Capacity
• 208-240 Volt Single Phase Input / 120 Volt Or 240 Volt Single Phase Output
• Built In Isolation Transformer To Suppress Electrical Noise For Sensitive Devices As Well As Protect Users From Faulty Equipment
• Tower
• Pure Sine Wave Clean Output To Operate And Maximize The Life Of Even The Most Sensitive Electronics
• Online (Double Conversion) - Highest Level Of Protection Available - Battery Power Always Engaged, No Switching Delay
• Accepts Generator Power (Direct or On Automatic Transfer Switch)
• Constant Voltage Regulation
• Constant Frequency Regulation
• Factory Warranty: 3 Years On Electronics And 1 Year Warranty On Batteries
• Optional Extended Warranty: 5 Years On Electronics And 2 Year Warranty On Batteries
• Heavy Duty Industrial Grade For Constant Use
• For Use With Laboratory Instruments
• For Use With Sensitive IT Equipment
• 0.7 Power Factor
• INPUT: Hardwire (No Outlets) 208-240 Volt Single Phase, 30 Amps
• OUTPUT: Hardwire (No Outlets) 120 Volt Or 240 Volt
• Typically Installed On A Branch Circuit By An Electrician
• Estimated Run Time/Backup Power Time On Battery Power:
• 18 Minutes 20 Seconds UPS Only
• 20x 12 Volt 7.2 Amp Hour Batteries
• 36 Minutes 41 Seconds UPS + 1 Battery Cabinet
• 40x 12 Volt 7.2 Amp Hour Batteries
• 55 Minutes 01 Seconds UPS + 2 Battery Cabinets
• 60x 12 Volt 7.2 Amp Hour Batteries
• Run Time/Backup Power Time Includes The Following Equipment
• G1310/11A Iso/Quat Pump
• G1312A Binary Pump
• G1322A Degasser
• G1313A Autosampler
• G1330A Sample Thermostat
• G1329A Autosampler
• G1316A Therm Column Comp
• G1314/5A VWD & DAD
• G1365A MWD
• G1321A FLD
• G1362A RID
• Laboratory Computer/Data System With Monitor
• BBP-6000-PSW-ONL-AGILENT-1100LC
• Configurable Output 120V or 240V (Not Simultaneous)
• For Use With Agilent 1100 Series Liquid Chromatograph
• Weight: 320 lbs.
• Dimensions (Inches): 16.3 x 29.9 x 36.6 (W x D x H)
• Operating Temperature: 32°-104° F
• Operating Humidity: 0 - 95%, Non-Condensing
• Operating Elevation: 11,482 Feet Maximum
• Cold Start Capable (Shipped With Cold Start Disabled, Will Enable Automatically After Receiving Power For The First Time After Shipping)
• Includes UPSMON Plus For Windows Monitoring & Configuration Software:
• Free Shipping/Freight Within The United States Or To U.S. Based Freight Forwarder Specified Location (List U.S. Based Location Specified By Forwarder In Shipping Address For International Orders)

User Guide:

Replacement Batteries:
-Type: 12 Volt 7.2 Amp Hour Batteries
-Make & Model Number: Yuasa NPW36-12 12V 7.2Ah or Equivalent
-Lowest Cost: $24.99 Each Plus Shipping On Amazon

Watch The Video Above To See How Easy It Is To Add Extra Backup Time

The Uninterruptible Power Supply (UPS) Inverter Capacity XXXX VA / XXXX Watts Determines How Many Watts Can Be Used From The UPS (How Large Of An Electrical Load). This Stays Constant Even If Extra Batteries Are Added. For Example, A 600 Watt UPS Can Run 10x 60 Watt Light Bulbs.

Extra Batteries Or External Battery Packs/Cabinets Increase Run Time (The Time Electronics Can Be Run On Battery Power). Extra Batteries Do Not Increase The Inverter Capacity (How Many Watts Can Be Used From The UPS). For Example, A 600 Watt UPS Can Still Only Run 10x 60 Watt Light Bulbs, But With Extra Batteries, It Can Run Those Light Bulbs Much Longer.

Get an estimation of how long your electronics will run on backup battery power with this unit during a power outage. Write down the Power Factor, Number of Batteries, Voltage of Batteries, and Amp Hour Rating from above, then to go to our .
